Taylor C707 Soft Serve Freezer Single Flavor Features
Offer all the popular soft serve variations from low or non-fat ice creams to custards, yogurt and sorbet.
One, 3.4 quart (3.2 liter).
One, 20 quart (18.9 liter). Separate hopper refrigeration (SHR) maintains mix below 41ºF (5ºC) during Auto and Standby modes.
Mix Low light alerts operator to add mix. When the Mix Out light flashes, the unit shuts down automatically to prevent damage.
SoftechTM is our exclusive microprocessor based master control that regulates refrigeration by measuring product viscosity to maintain consistent quality.
During long no-use periods, the standby feature maintains safe product temperatures in the mix hopper and freezing cylinder.
Digital Temperature Indicator
Hopper temperature is displayed to assure safe product temperatures. Indicator may be switched from Fahrenheit to Celsius temperature display.
Taylor C707 Soft Serve Freezer Specifications
One dedicated electrical connection is required. See the Electrical chart for the proper electrical requirements. Manufactured to be permanently connected. Consult your local Taylor distributor for cord & receptacle specifications as local codes allow.
One, 1.5 HP.
One, 9,500 BTU/hr. R404A. Separate Hopper Refrigeration (SHR), One, 400 BTU/hr. R134a. (BTUs may vary depending on compressor used.)
Minimum 6” (152 mm) on both sides and place the back of the unit against a wall to prevent recirculation of warm air. Minimum air clearances must be met to assure adequate air flow for optimum performance. Optional air discharge chute directs heated air exhaust upwards. No clearance required on right side if air discharge chute is used.
Water inlet and drain connections out rear panel 3/8” FPT. Provided with 4-1/4” (108 mm) legs, which increases height of unit.
Taylor C707 Soft Serve Freezer Options
- Cart with casters-height to top of hopper cover: 59-1/8” (1502 mm)
- Cone Dispenser
- Decals – Vanilla or Flavor Burst Cone
- Hopper Locks
- Legs – [increase height of unit by 4-1/4” (108 mm)]
- Syrup Rail (front mount requires special cart with rear door)
- Syrup Rail Kit (side mount)
- Top Air Discharge Chute (air cooled only)
C201 Cart Weights:
Net: 110 lbs. (49.9 kg) Crated: 143 lbs. (64.9 kg) 23.8 cu. ft. (0.67 cu.m) Continuing research results in steady improvements; therefore, these specifications are subject to change without notice.
